Features
1.Integrated Versatility: One Machine, Infinite Possibilities. TLP 330 combines printing, laminating, cutting, and slitting in one device, simplifying and enhancing your production process.
2.Excellent Printing Performance: Whether it's white, varnish, or colored UV inks, the TLP 330 provides excellent printing effects on various media, making your labels stand out on the shelf.
3.High precision cutting: With ball screws and independent servo motors, it achieves ±0.05mm cutting accuracy for flawless labels.
4.Wide Range of Applications: From food packaging to electronic product identification, from cosmetic labels to industrial data encoding, the LQ-MD UV330 can easily handle it all.
| Printing unit Equipped with 4 EPSON I3200-U1 print heads, it enables high - speed printing of four colors plus white and gloss varnish, enhancing label texture and visual appeal. It handles both small and large orders with ease. |
| Buffer The buffer stores label design data in real time and auto compensates for speed differences between printing and cutting, preventing film stretching, deformation, or wrinkle formation. |
| Cutting unit The cutting unit uses servo motors controlled pressure, eliminating manual adjustment, reducing downtime, and boosting production efficiency.
|
| Automatically control Self-developed interface enables color, speed, and database integration, making the entire process easy to learn and operate. |
Specification |
Model | TLP 330 |
Maximum Roll Diameter | 320 mm |
Maximum Media Width | 330 mm |
Printhead | EPSON i3200-U1×4 |
Ink Type | UV Ink |
Ink Colors | CMYK+W+V, CMYK |
Ink Bottle Capacity | 1000 ml |
Printing Speed | 4 pass: 56 m²/h 6 pass: 40 m²/h 8 pass: 28 m²/h |
File Formats | JPG, PDF |
Cutting Length | 10-300 mm |
Cutting Width | 20-320 mm |
Repeat Die-cutting Accuracy | ±0.05 mm |
Number of Die-cutting Heads | 2 |
Number of Slitting Knives | Standard 4 (optional according to requirements) |
Weight | 1800 Kg |
Power | 4KW AC220V 50HZ/60HZ |
Dimension | 2200×1800×1700 mm |
Application |
